PD765-7R3-00 New

Process Control Universal Panel Meter

All standard process signals including Thermocouple and RTD!

• Shallow Depth Case 3.6" Behind Panel
• Type 4X, NEMA 4X, IP65 Front
• Universal Power Supply 85-265 VAC
• Two Relays Option with Alternation
• 4-20 mA Analog Output Option
• 24 VDC @ 200 mA Transmitter Power Option
• RS-232, RS-422/485 Serial Communication Options
• Modbus® RTU Option Now Available
• Sunlight Readable Display
• 3 Year Warranty

This version of the PD765, PD765-6R0-00, has No options, and is 85-265 VAC Powered

Details Specifications
